In This Issue:

1. DA-400         – DA 400 – AC/DC Parker Contour Probe

2. News            – Application Support

3. News            – From the Sales Desk  – Foerster – Karl Deutsch

4. Application  – Inspection of Valve Spring Wire with Special Geometry





31-2018-July-September-Probe1

31-2018-July-September-Probe1a

Product Description

  • VERSATILITY AND POWERFUL PERFORMANCE IN A DEPENDABLE INSTRUMENT
  • CONSTANT AC OR HALF WAVE RECTIFIED (DC) FIELDS WITH THE FLIP OF A SWITCH
  • APPLY CONTINUOUS FIELDS or DEMAGNETIZE
  • USE WITH DRY POWDER, WET FLUORESCENT OR VISIBLE INKS
  • STRONG HIGH IMPACT MOLDED HOUSING
  • FULLY REPAIRABLE
  • ONE YEAR GUARANTEE
  • FREE YOKE LIGHT INCLUDED
  • FROM PARKER THE ORIGINATOR OF THE ARTICULATED LEG YOKE



 The DA-400S Contour Probe has a selective AC and DC function, built into this single reliable instrument.

The AC mode produces an intense AC field for detection of surface defects & demagnetizing after inspection.

The DC mode produces an intense Half Wave Rectified DC field for detection of applicable subsurface defects.

Controls and solid-state electronics are contained within the high impact moulded housing. Articulating legs allow the AC or DC field to be applied to the precise area of inspection on nearly any part or surface shape.

Like more Information – 02 8850 3755



31-2018-July-September-Probe2a

Application Support Switzerland

Takuya Den PhD in chemistry has joined Fischer in Switzerland as one of our new application engineers.

In addition, our testing and calibration lab in Switzerland just passed the renewing audit from the Swiss accreditation service according to ISO17025. The lab is accredited for the many services as shown below.



31-2018-July-September-Probe2

Like more Information – 02 8850 3755





31-2018-July-September-Probe3

31-2018-July-September-Probe3aThe module consists of a variety of J-Sensors for different steel bar diameters and a J-H application software package. Main focus is on the following industrial applications:

  • Determine the complete J-H hysteresis for soft-magnetic steel including saturation Hmax, Jmax and remanence Jr
  • Determine the relative magnetic permeability μr
  • Determine the hysteresis loss (core loss) W

All these are important material properties when manufacturing components for electromagnetic actuators and electrical drives.













31-2018-July-September-Probe3bKarl Deutsch Introduces Phased Array technique on their new ECHOGRAPH-STPS-PAUT Bar testing System

ECHOGRAPH-STPS testing systems normally contain 9 or 15 probes,

which already provide a good coverage of the bar cross section. By using the phased array technique the number of ultrasonic shots is increased and fuller cross-sectional coverage is achieved. Providing greater throughput of Bar.



31-2018-July-September-Probe3c

Like more information

02 8850 3755



31-2018-July-September-Probe4

31-2018-July-September-Probe4a

Have any questions or like further details?;

contact us now !

Ph 02 88503755 or Email
